Aluminum foil container production line

FOB Reference Price:Get Latest Price
$30,000.00 - $100,000.00 / Set | 1 Set/Sets for Aluminum foil container production line (Min. Order)
Shipping:
Support Sea freight
Report Suspicious Activity
Overview
Quick Details
Condition:
New
Automatic Grade:
Automatic
Usage:
Other Forming Machine
Place of Origin:
Jiangsu, China
Brand Name:
Goldshine
Model Number:
GS-JF21-45
Voltage:
380V/220V
Power:
5.5kw, 5.5kw
Dimension(L*W*H):
1550*1150*2500mm
Weight:
45T, 3800-4500KG
Certification:
CE
Type:
Multi-Function Packaging Machine
Packaging Material:
Wood
Application:
Machinery & Hardware
Driven Type:
Electric and pneumatic
Function:
Pressing
Packaging Type:
Wooden case
OEM:
Yes
Keywords:
Aluminium foil machine
After-sales Service Provided:
Engineers available to service machinery overseas
Warranty:
1 Year
Supply Ability
Supply Ability:
10 Set/Sets per Year for Aluminum foil container production line
Packaging & Delivery
Packaging Details
Wooden case for Aluminum foil container production line
Port
shanghai
Lead Time :
50-60 days after payment

Aluminum foil container production line

Product Description

Performance Characteristic for Aluminum foil container production line

1. This machine adopts Siemens CPU216 programmable logic container(PLC) as the controlling system. It is reliabale. The feeding length, producing speed and other parameter are easily set. It is integration of Gas & Electrical, centralized control, automated production.
2. Feeding, punching, scrap collecting is running automatically.
3.The accurate press adopts steel plates joining body, variable frequency speed regulation, dry type friction clutch to clutch-on-off,rigid over-load protector to protect the press. In short, this is a high accuracy and reliability press.
4. Feeding is controlled by stepper system, the feeding length is accurate and can be adjusted from 20mm to 999mm.

Main specifications and technical parameters

1.Feeding machine



2.High Accuracy Press


Model
JF21-45
JF21-63
JF21-80
JF21-110
Nominal Pressure
(KN)

450

630

800

1100
Slide Block Strok
(mm)
100-260mm
120-260mm
140-260mm
150-260mm
Slide Stroke Per Minutes(/min)

70-50

70-50

60-45

50-40
Maximum Die Set Height(mm)
270-400
310-450
325-450
345-500
Die Set Height Adjustment(mm)
60mm(2.36)
70mm(2.76)
80mm(3.15)
90mm(3.54")
Slide Bottom Size
 (mm)
410*340mm
480*400mm
560*460mm
630*520mm
Stemhole Size(mm)
φ60*60mm
φ60*65mm
φ60*75mm
φ60*85mm
Bolster Surface Size
(mm)
810*440/990*750mm
870*520/1000*800
1000*600/1200*800
1100*680/1300*800mm
Total Power
 (KW)
5.5
5.5-7.5
7.5-11
11-15
Weight(kg)
3800-4500
5500-6300
8000-9000
11000-12000
Overall Dimension Before Changed(mm)
1440*1080*2300mm
1610*1200*2500mm
2000*1300*2900mm
2030*1500*3130mm
Overall Dimension After Changed(mm)
1550*1150*2500mm
1800*1300*2700mm
2200*1450*3100mm
2300*1600*3300mm

3.Mould



4.Scrap Collrcting Device

 4.Stacker

If this product is not what you need, please do not worry.

We can design according to customer's size, style, logo ect.



Packing & Delivery

    Film packaging



Wooden box packaging

Related products

Company Information

Goldshine is  China's outstanding OEM and ODM

Established in 2005

Welcome to visit our factory.

Zhangjiagang goldshine aluminum foil co.,ltd. is a leading company engaged in the research, development, production and sale of aluminum foil and aluminum foil relevant products, established in 2005,located in Zhangjiagang City.

Our company has a plant area of over 20000 square meters, the superior geographical environment and convenient traffic conditions make goldshine aluminum foil quickly into the international market.

Our company's products are exported to U.S., EU, Japan, Australia and more than 70 countries and regions, enjoy a good reputation in the international market with best service and high quality products.

The main products: aluminum foil jumbo roll, aluminum foil, aluminum foil container, aluminum foil roll machine, POP-UP foil sheets and so on.

Our customer
FAQ

Q: Are you trading company or manufacturer ?

A: We are manufacturer.

Q: How long is your delivery time?

A: Generally it is 15-35 days, it is according to your quantity.

Q: Can you do the machines' appearance design for us?

A:Yes. We have a professional team with rich experience in machne's apperance design and manufacturing.

Q: What is your terms of payment ?

A: L/C,D/A,D/P,T/T,Western Union.

Q:Can you do the machines' appearance design for us?

A:Yes. We have a professional team with rich experience in machne's apperance design and manufacturing.

Q:What's your after-sale service?

A:Our own engineers could be asked by you overseas for your serve. You can also ask your staff or yourself to our factory to learn.

If you have any questions, please do not hesitate to contact us.
